Highlights

• Seamlessly combine hydraulic subsystems and components with other domains in a single environment for system-level modeling
• Choose from over 150 components for modeling pumps, motors, cylinders, restrictions, valves, hydraulic lines, lumped volumes, and sensors
• Incorporate compressible oils and cavitation effects into your models
• Select from a set of predefined standard hydraulics oils or define your own
• Easily reuse, customize, and extend components to suit your specific needs
• Generate highly efficient, royalty-free simulation code
• Control the level of model detail according to your needs, with base components suitable for real-time and hardware-in-the-loop simulations and advanced components that take into account more physical factors and give you an extremely precise view of system behavior
• Access underlying system equations for advanced analysis, parameter optimization, and visualization in Maple
• Get started quickly with sample models that can be modified to form a starting point for your own designs

The MapleSim Hydraulics Library from Modelon contains over 150 components for advanced hydraulics modeling, including:

• Cylinders: single and double acting, plunger, differential
• Directional control valves: with and without spool dynamics
• Lines: long, flexible, rigid
• Pumps: ideal, lossy, motor
• Restrictions: simple, laminar, laminar/turbulent, with or without cavitation
• Sensors: pressure, volumetric flow
• Volumes: piston-gas, spring-accumulator, chamber
• Fluids: oil with or without dissolved gas
